Countersinks CBN DIN335 C/90° HSSG 15,0 mm

Countersinks have a tapered blade geometry.
The most common versions are here: 60°, 90° and 120°. They are used for lowering, deburring and chamfering.

90° countersink are used primarily for reductions Flathead. DIN 335 Form C HSS / HSSE CBN ground version

The GSR countersink are produced according to the latest methods and ground with CBN wheels (CBN = cubic boron nitride), giving us a high surface quality,
Sharpness and longer service life compared to traditional ground-lowering guaranteed.

Size: 15,0mm

We offer the countersink in two quality levels:

HSS-G: (high speed steel ground)

HSSG TIN: (The TiN coating is for years the first choice for the coating of cutting tools and has established itself as an "all round" Finish The.
Coating is achieved a reduction in the friction coefficient and the tendency to galling.)

HSSE: (VA INOX stainless steel)

Tip!
For the machining of aluminum, a TiN coated countersink is recommended that remain otherwise glue the aluminum chips
